Ball valve with counterflange

Ball valve with counterflange

Shut-off valve with counterflange, designed for connection to component with oval flange, e.g. for circulation pumps.

Ball valve with counterflange

  • Variants
  • Detailed Information
  • Documentation

Variants

Ball valve with counterflange - Female thread

Ball valve with counterflange - Female thread 1 artikel

Article Dim. Weight (kg) Item List
189048 G 1" fem. 0.3

189048

Dim. G 1" fem.
Weight (kg) 0.3
Item list

Detailed Information

Description

Shut-off valve with counterflange, designed for connection to component with oval flange, e.g. for circulation pumps.

Technical Data

Max. working pressure: 1 MPa
Working temperature: Max. 120 °C
Thread standard: G - female thread
Material, sealing: PTFE
Material, ball valve: Brass MS 58
Material, ball: Chrome plated
Material: Hand actuator: Chisel grip
Other data:
Material, flange gasket Flange gasket in NBR supplied
Other data: Flange gasket in NBR supplied
Hand actuator Chisel grip

Documentation

Product sheet

Ball valve with counterflange
